xml-parser.png Workflow XML Parser Tool

概要

Use the Workflow XML Parser tool to extract workflow properties, tool configurations, and connection details.

Use the Workflow XML Parser tool to extract workflow properties, tool configurations, and connection details.

Marketplace Tool

This tool is not automatically installed with Alteryx Designer. To use this tool, download it from the Alteryx Marketplace.

Requirements and Compatibility Notes

  • The Workflow XML Parser tool is compatible with Designer and Server version 2022.1 and newer.

  • The tool is compatible with both Alteryx Multi-threaded Processing (AMP) and the original Engine.

Tool Components

The Workflow XML Parser tool has 4 anchors:

  • Input anchor: I input anchor: This anchor serves as the tool's input and should contain the target workflow XML in a single record.

  • Output anchors:

    • W (Workflows) output anchor: This anchor outputs your workflow properties. This includes all elements from the Properties and MetaInfo sections of the Workflow XML. Events, Constants, and RuntimeProperties are output as XML objects since many child elements can exist for each parent element.

    • T (Tools) output anchor: This anchor outputs your tool properties. The most common tool configuration elements are parsed and the full tool XML is provided for further analysis. Refer to the section below for details on what elements are parsed.

    • C (Connections) output anchor: This anchor outputs all connection details, including all origin and destinations along with the anchor names.

Configure the Tool

This tool requires the entire workflow XML to reside in a single cell (single column and single row) of your input data. To best achieve this, open files using the Blob Input tool to pull the yx* binaries into the workflows. Then, convert the workflow binaries to a string using the Blob Convert tool set to UTF-8.

Choose field that contains Workflow XML: Select the field (column) that contains the workflow XML string.

Workflow Output Fields

Field Name

Description

Menu Location

Menu Item

Corresponding Option

Values

Notes

Workflow_yxmdVer

The version of Alteryx Designer that was used to modify the workflow last.

Auto Created*

Built-in

YYYY.X

Workflow_RunE2

Is the AMP engine enabled for the workflow?

Runtime

Use AMP Engine

T or Null

Property_XML

Full XML for the "Properties" section.

N/A

N/A

N/A

Properties_Memory_max

Specific Memory Amount defined by the user (in MBs).

Runtime

Memory Limit (MB)

Integer

Properties_Memory_default

True: Use Global Default,

False: Use Specific Amount.

Runtime

Memory Limit Radio

True or False

Properties_GlobalRecordLimit

The user-defined limit for all inputs (blank = no limit).

Runtime

Record Limit for All Inputs

Integer

Properties_TempFiles

A specific temp folder defined by the user.

Runtime

Use Specific Folder

Folder Path

Properties_TempFiles_default

True: Use Global Default,

False: Use Specific Folder.

Runtime

Temporary Files Radion

True or False

Properties_Annotation_on

The Annotations visibility setting.

Canvas

Annotations

True or False

Properties_Annotation_includeToolName

Are Annotations displayed with the tool name?

Canvas

Annotations

True or False

Properties_ConvErrorLimit

Number of conversions to limit (0 = no limit).

Runtime

Maximum Errors per Location

Integer

Properties_ConvErrorLimit_Stop

Stop processing when the limit is reached.

Runtime

Checkbox

True or False

Properties_CancelOnError

Cancel running the workflow on error.

Runtime

Checkbox

True or False

Properties_DisableBrowse

Disable all Browse tools.

Runtime

Checkbox

True or False

Properties_EnablePerformanceProfiling

Enable Performance Profiling.

Runtime

Checkbox

True or False

Properties_RunWithE2

Use AMP engine.

Runtime

Checkbox

True or False

Properties_SortedGrouping

Engine Compatibility Mode.

Runtime

Checkbox

True or Null

Properties_PredictiveToolsCodePage

The code page to use for Predictive tools in the workflow. This setting overrides the selection in Language and Region User Settings.

Runtime

Dropdown

Code page values.

Properties_DisableAllOutput

Disable all tools that write output.

Runtime

Checkbox

True or False

Properties_ShowAllMacroMessages

Show all macro messages.

Runtime

Checkbox

True or False

Properties_ShowConnectionStatusIsOn

Determine what level of Connection Progress is shown (False = hide).

Canvas

Connection Progress

Dropdown

True or False

Properties_ShowConnectionStatusOnlyWhenRunning

Determine if connection progress is shown only while running.

False = Show,

True = Show only when running.

Canvas

Connection Progress

Dropdown

True or False

Properties_ZoomLevel

The zoom value when opening the workflow.

Built-In

Built-In

Integer

Properties_LayoutType

The direction of the tool layout in the canvas.

Canvas

Layout Direction

Dropdown

Horizontal or Vertical

Properties_IsTemplate

Defines if the workflow is a template (YXTD).

Built-In

Built-In

True or False

MetaInfo_NameIsFileName

Meta Info

Use File Name

Radio Button

True or False

MetaInfo_Name

Meta Info

Custom

Radio, Text Input

Text

MetaInfo_Description

The description of the workflow shown either in Server, on the App splash screen, or on hover in the Designer tool palette.

Meta Info

Description

Text Input

Text

MetaInfo_RootToolName

The root tool name that helps identify versions to group.

Meta Info

Root Tool Name

Text Input

Text

Macros Only

MetaInfo_ToolVersion

The version of the tool to use when multiple macros exist with the same RootToolName.

Meta Info

Tool Version

Text Input

Text

Macros Only

MetaInfo_ToolInDb

Identifies if the macro is an In-Database tool.

Meta Info

Tool In-Database?

Checkbox

True or False

Macros Only

MetaInfo_CategoryName

The category where the macro can be found in the Designer tool palette.

Meta Info

Category Name

Text Input

Text

Macros Only

MetaInfo_SearchTags

The keywords used to find the tool when searching.

Meta Info

Search Tags

Text Input

Text

Macros Only

MetaInfo_Author

The name of the workflow author.

Meta Info

Name

Text Input

Text

MetaInfo_Company

The company of the workflow author.

Meta Info

Company

Text Input

Text

MetaInfo_Copyright

The copyright information for the workflow.

Meta Info

Copyright

Text Input

Text

MetaInfo_DescriptionLink_actual

The description link (used in the interface for apps and in the tool palette for macros).

Meta Info

URL

Text Input

Text

MetaInfo_DescriptionLink_displayed

The description link display text (used in the interface for apps and in the tool palette for macros).

Meta Info

Display Text (optional)

Text Input

Text

MetaInfo_WorkflowId

The current workflow ID of the file.

Built-In

MetaInfo_Telemetry_PreviousWorkflowId

The previous workflow ID of the file.

Built-In

MetaInfo_Telemetry_OriginWorkflowId

The initial workflow ID of the file.

Built-In

MetaInfo_PlatformWorkflowId

The corresponding platform workflow ID.

Built-In

MetaInfo_Example_Description

The hyperlink text to display (for example, "Open Example").

Manual XML Entry

MetaInfo_Example_File

The file path for One Tool Example workflow.

Manual XML Entry

The example file path needs to be present in the Samples\Learn one tool at a time folder.

Events_OuterXML

The full XML object for all Events.

Constants_OuterXML

The full XML object for all Constants.

RuntimeProperties_OuterXML

The full XML object for all Runtime Properties.

MetaInfo_OuterXML

The full XML object for all MetaInfo for the workflow.

Tool Output Fields

警告

Tools can have multiple rows if there are 2 or more of the elements parsed. This is common in the Formula tool along with tools that have multiple file connections.

注記

Rows with ParentIds and null ToolIds are empty tool containers.

Field Name

Description

Relevant Tools

ToolID

The ToolID of the node.

All

Origin_Tools

The ToolIDs of upstream tools. Data originates from these tools and flows into the specified tool.

Any tool that is connected to an upstream tool.

Destination_Tools

The ToolIDs of downstream tools. Data originates from the specified tool and flows into these tools.

Any tool that connects downstream to another tool.

ParentToolId

The Tool Container or Control Container ToolID in which the specified tool is located.

Only filled in when the tool is in a container.

EngineSettings_EngineDll

The tool-specific EngineDll.

EngineSettings_EngineDllEntryPoint

The tool-specific EngineDllEntryPoint.

EngineSettings_Macro

The tool-specific macro path (only applicable for macros).

GuiSettings_Plugin

The tool-specific Gui Plugin.

GuiSettings_Position_x

The tool canvas horizontal location.

GuiSettings_Position_y

The tool canvas vertical location.

GuiSettings_Position_width

The tool width.

GuiSettings_Position_height

The tool height.

Properties_OuterXML

The full XML element for the tool properties.

Properties_Configuration_joinByRecordPos

True and False settings for whether the Join tool is set to "Join by Record Position."

Join, Join Multiple

Annotation_OuterXML

The full XML for annotations.

Properties_Annotation_DisplayMode

The display mode of tool annotation (Canvas Settings, Always, Never).

Properties_SdkSettings_Manifest

True or False for Manifest.

SDK Tools

Properties_SdkSettings_Language

The SDK language used.

SDK Tools

Properties_SdkSettings_PluginDir

The stored directory for the SDK tool.

SDK Tools

Properties_SdkSettings_Transport

The language-specific transport layer.

SDK Tools

Properties_SdkSettings_OuterXML

The full XML for tool SDK settings.

SDK Tools

Configuration_OuterXML

The tool XML (accessible in tool configuration).

Dependencies_OuterXML

The full XML for tool-specific dependencies.

MetaInfo_OuterXML



Formula_Field

Formula Field Name

Formula Tool

Formula_Size

Formula Field Size

Formula Tool

Formula_Type

Formula Field Type

Formula Tool

Formula_Enabled

Describes if the formula expression is enabled.

Formula Tool

Expression

Formula Expression

Dynamic Select, Filter, Formula, Multi-Field Formula, Multi-Row Formula

Field Name

Description

Relevant Tools

Filter_Simple

Formula Expression

Filter Tool

Filter_Field

Simple filter field selected.

Filter Tool

Filter_Operator

Simple filter field operator.

Filter Tool

Filter_Operands

Simple filter operands.

Filter Tool

DefaultAnnotationText

The default annotation text of a tool.

Any

AnnotationText

The custom annotation text of a tool.

Python_JupyterProduction

True or False setting to determine if Jupyter is set to run in production mode.

Python Tool

Python_vEnvName

The Python environment used for running the script.

Python Tool

Python_vEnvName_OuterXML

The full XML for the vEnvName element.

Python Tool

Python_Notebook

The script run while the Python tool is in interactive mode.

Python Tool

Python_productionModeScript

The script run while the Python tool is in production mode.

Python Tool

RScript

The script run in the R tool.

R Tool

File_File

The full file path entered in the text box.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_OutputFileName

Determines if the file name is output as a full path or only the file name.

File_FileFormat

The numeric value for the file format.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_SearchSubDirs

The option checked to Search Sub Directories for a file.

File_RecordLimit

The record limit for file input.

File_OuterXML

The full XML for the file element.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_MaxRecords

The record limit for file output.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_Table

The table referenced as a part of the file input.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_CreateMode

In-DB Create Mode

In-DB

CreateMode_OuterXML

The full XML for In-DB Create Mode.

File_PreSQL

The PreSQL statement run prior to executing a query.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

File_PostSQL

The PostSQL statement run after executing a query.

Dynamic Input, Input Data, Macro Input, Output Data, Run Command

RScript_OuterXML

The full XML for the R script element.

FileFormatName

The readable format name for file format referenced in File_FileFormat.

DesignerToolName

The tool name as seen in Designer.

DesignerToolCategory

The tool category as seen in Designer.

ToolGroup

Connection Output Fields

Field Name

Description

Origin_ToolID

The tool ID at the beginning of the connection.

Origin_Connection

The anchor name at the beginning of the connection.

Destination_ToolID

The tool ID at the end of the connection.

Destination_Connection

The anchor name at the end of the connection.

name

Connection Name

Wireless

Is the connection wireless (True or False)?
